Turnkey Grain Storage & Logistics Centers
Complete silo storage, conveying, cleaning, and automation systems for grain, oilseeds, and bulk materials.
Large-Capacity Storage
Single silos up to 10,000 t; expandable silo complexes to 50,000+ t
High-Efficiency Material Handling
Conveying systems from 10–2,000 t/h with minimal grain breakage
Smart Monitoring & Automation
Temperature, level, and PLC-based control for safe storage
Custom Silo Engineering
Flat-bottom, hopper-bottom, and insulated silos for different materials
Our Turnkey Storage Project Delivery Process
Site analysis, capacity planning, foundation design
Custom silo sizing, material selection, layout
In-house 130,000㎡ factory, ISO certified
On-site assembly, conveying integration, testing
Why Choose AmGrainTech Storage & Logistics Solutions?
- Integrated system engineering : From grain receiving to final outloading, we design complete storage and handling systems including silos, conveyors, cleaners, and automation.
- Proven silo technology: Bolted steel silos made from high-strength galvanized sheets (275–450 g/m² coating) for corrosion resistance and long service life.
- Efficient conveying: Air-supported, en-masse, screw, and bucket elevators tailored to your material and distance.
- Intelligent automation: PLC-based control with remote monitoring, temperature sensing, and inventory management.
Storage Capacity & System Selection Guide
Choose the right scale and silo type for your operation.
| Scale | Storage Capacity | Recommended Silo Type | Key Equipment | Typical Application |
|---|---|---|---|---|
| Small / Farm | 500 – 5,000 t | Hopper-bottom silos | Bucket elevators, screw conveyors, basic control | Farms, small cooperatives |
| Medium / Regional | 5,000 – 15,000 t | Flat-bottom silos (assembly type) | En-masse conveyors, chain conveyors, temperature monitoring | Grain stations, feed mills |
| Large / Industrial | 15,000 – 50,000 t | Flat-bottom silos with aeration | Air-supported conveyors, automated gates, PLC central control | Ports, large reserves, processors |
| Mega / Terminal | 50,000 t+ | Multiple silo banks, insulated if needed | High-capacity conveying, advanced automation, remote management | Export terminals, mega feed mills |
Typical Grain Storage & Handling Process Flow
A complete storage center integrates receiving, cleaning, conveying, silo storage, monitoring, and outloading to ensure safe grain preservation.
Grain is received from trucks or trains, weighed, and sampled.
Remove impurities with drum screens and magnetic separators.
Bucket elevators and belt conveyors transport grain.
Temperature monitoring, aeration, inventory tracking.
Grain reclaimed, cleaned, and loaded for dispatch.
Key Equipment Used in Our Storage & Logistics Centers
High-quality machinery for every stage of the handling chain.
- Steel Silos – Bolted flat-bottom, hopper-bottom, and insulated silos (500–50,000t).
- Conveying Systems – Air-supported, en-masse, screw, and bucket elevators.
- Cleaning Equipment – Drum screens, magnetic separators, gravity classifiers.
- Control & Monitoring – PLC-based automation, temperature sensors, radar level sensors.
- Auxiliary Equipment – Gates, valves, sweep augers, dust collection systems.
Typical Grain Storage Center Investment Range
Estimate your budget based on capacity, automation level, and site conditions. The total investment for a storage and logistics center depends on capacity, silo type, conveying distance, automation level, and civil works. Below is a general reference:
- Small / Farm scale (500–5,000 t): $100,000 – $500,000
- Medium / Regional (5,000–15,000 t): $500,000 – $1.5M
- Large / Industrial (15,000–50,000 t): $1.5M – $5M
- Mega / Terminal (50,000 t+): $5M – $15M+
Note: Final quotation requires a detailed site assessment and engineering design.
